Self-Tracking Belt Stainless Steel Mesh Conveyor Belt In Wide
Variety Of Industries
Self-Tracking Belt is a very versatile type of belting.
This type of belting is used in a wide variety of industries,
including food and pharmaceuticals, chemicals, plastics and
polymers.
Process applications that can be accomplished include washing,
draining, drying, curing, cooking and freezing.
Feature :
1.Self-Tracking; the belt does not need any tracking or steering
device as this is built into the design of the belt itself
2.No stretching; the longitudinal wires are made from pretensioned
cables, therefore the stretching of the belt is reduced even under
high tensioning
3.No wear; the more sensitive cable wires do not touch the rollers,
they are safely located in the V-shaped sections of the solid cross
wires.
4.High Flexibility; the flexibility of the cable in the running
direction considerably improves the resistance to metal fatigue,
even at high speed on small diameter pulleys
Self -Tracking Metal Conveyor Belts Application
Our metal wire conveyor belt is widely used for different conveyor
systems like cooling, frozen, cleaning and heat treatment etc. We
have plenty experience of different conveyor belt design to work
with different conditions. Either from electronics or food,
printing or coating, our belt is powering a huge industry for
smooth production.
Self -Tracking Wire Mesh Belt Properties| Material | Any class stainless steel upon requirement |
| Standrad | DIN, JIS |
| Type | Wire mesh conveyor belt |
| Mesh size | Choose from over 50 available models |
| Thickness | 10-40mm in total |
| Width | 300-2000mm |
| Length | By customer requirement |
| Application industry | mainly used in heating/tempering equipments. |
| Introduction | Wire mesh conveyor belt is spiral coils connection |
| Features | Acid-resisting, alkali-resisting, high temperature resisting,
strong tension and good abrasion performance
It also has advantage of stable, fine and high precision filtering
performance.
Long service life |
Self -Tracking Stainless steel general properties table
Grade | Composition(%) | Temperature resisting | Specifications |
C | Si | Mn | Ni | Cr | Mo |
1Cr13 | ≤0.15 | ≤0.6 | ≤0.6 | - | 12-14 | - | 650℃ | Normal conveyor use |
1Cr17 | ≤0.15 | ≤0.6 | ≤0.6 | - | 12-18 | - | 650℃ | |
304M | ≤0.06 | ≤1.0 | ≤0.6 | 8.9-10 | 18-20 | - | 920℃ | Normal conveyor use |
304L | ≤0.03 | ≤1.0 | ≤0.6 | 9-13 | 18-20 | - | 920℃ | intercrystalline corrosion |
316 | ≤0.08 | ≤1.0 | ≤0.6 | 10-14 | 16-18 | 2-3 | 920℃ | Anti corrosion |
316L | ≤0.03 | ≤1.0 | ≤0.6 | 12-15 | 16-18 | 2-3 | 920℃ | intercrystalline corrosion |
309S | ≤0.08 | ≤1.0 | ≤0.6 | 12-15 | 22-14 | - | 1000℃ | Continuous high temperature |
| 310s | ≤0.08 | ≤1.5 | ≤0.6 | 19-22 | 24-26 | - | 1100℃ | High temperature & heavy hit resisting |
314 | ≤0.25 | 1.5-3.0 | ≤0.6 | 19-22 | 23-26 | - | 1200℃ | Antioxidant plus all 310S |
Cr20Ni80 | ≤0.15 | 0.4-1.3 | ≤0.6 | 72-78 | 20-23 | - | 1200℃ | Antioxidant & high temperature resisting |
Why Choose Us
1. Quick Production
We have a solid production team with over 12 years, each operator
has been working in this industry for more than 5 years. Plus, we
have more than 50 existing moulds to use directly.
2. Direct Manufacturer
We're direct manufacturer since 2003, we're also very close to sea
port & airport. We are the earliest manufacturer from south China.
3. Custom design
We have a professional engineering department for quick design upon
customer requirements.
4. Competitive price
We are running mass production model and have built up advanced
partnership with source material providers. We can save much cost
and provide very promotional offer to clients.
5. Best After-sale Service
We have professional after-sales service team, which consist of
five people, and each has more than three years experience. If you
have any questions after you receive the cargo, you can call us or
send email all day.
6. Supply free samples
As we have above advantages, we can supply you free samples for
your trial to test if you have great intention to order
