Chain Driven Conveyor Belt Drive Rollers , Heavy Duty Metal Conveyor Rollers

Ask Lasest Price
Brand Name :	Guangya
Model Number :	GY-LP03
Certification :	ISO9001-2008
Price :	negociable
Payment Terms :	L/C, T/T, Western Union
Supply Ability :	3000 square meters per month
Delivery Time :	5-10 days

Add to Cart

Product Details
Company Profile

Chain Driven Conveyor Belt Drive Rollers , Heavy Duty Metal Conveyor Rollers

2017 Hot Sale Economical Chain Driven Live Roller Conveyor Systems

Chain Driven Live Roller Conveyors, commonly referred to as CDLR, provides a positively driven, heavy duty, live roller conveyor. Because of the positive chain and sprocket drive, it's an ideal choice for conveying pallets, containers, drums and other heavy unit loads. In addition, it's well suited for dirty or oiling environments, where other types of live roller conveyors won't perform .

Application:

• Unitized

• Totes or slab Pallets not strong enough to be supported by chain conveyor

• Pallet loads when bottom boards are perpendicular to the rollers

• Pallet loads when bottom boards are parallel to the rollers

• Side loading/unloading

• Accumulation of loads

• Loads that must be aligned

Chain Driven Conveyor Belt Drive Rollers , Heavy Duty Metal Conveyor Rollers

Conveyor Roller Parameter

Model	Roller		Frame			Bearing(kg/m)
Model	Diameter	L	Spacing	Size	L	Bearing(kg/m)
GA-25	ø25	150-600	30.40.50	40202	1000-3000	30
GA-38	ø38	150-600	50.75.100	60302.5	1000-3000	300-80
GA-50	ø50	150-1000	75.100.120	60303	1000-3000	500-100
GA-60	ø60	150-1000	50.75.100	90303	1000-3000	600-150
GA-76	ø76	150-1000	100.150	120303	1000-3000	1000-500

Product Name	Good price chain driven live roller conveyor China manufacturer
Models	Double Steel roller type
Length(Closed/Expended)	2000mm - 4800mm (6.6'-15.7')	2500mm - 6000mm (8.2'-20')
Width	400mm, 500mm, 600mm, 18'', 24''
Height (Adjustable)	620-990mm (24.4''-39'')	710-1120mm (28''-44'')
Load Capacity	300kg/m (100lbs/ft)
Roller	Ø50mm Steel Roller With Precision Bearing Inside
Key Word	roller conveyor

Conveyor Chain FAQ

Q: What's the lead time?
A: It takes 5-10 days for production in factory depends the total quantity. Each belt is custom made based customer side exact parameters.

Q: How long is your company in business?
A: We shenzhen guangya wire belt company started business in 2003 and only dedicated to stainless steel chain & wire belt production.

Q: How do I order?
A: If you can visit our company, we can fix all technical details quickly by live discussion. We can also send you drawing so you can specify needed configuration. Once the wire belt structure is confirmed, we will sign contract. We accept T/T & L/C payment.

Q: How can I verify the belt?
A: Before delivery, you can send engineer to verify it by agreed technical design.
