Triple Strand Roller Conveyor Chain Stainless Steel Short Pitch Custom Design

Ask Lasest Price
Brand Name :	Guangya
Model Number :	GY-LP03
Certification :	ISO9001-2008
Price :	negociable
Payment Terms :	L/C, T/T, Western Union
Supply Ability :	3000 square meters per month
Delivery Time :	5-10 days

Add to Cart

Product Details
Company Profile

Triple Strand Roller Conveyor Chain Stainless Steel Short Pitch Custom Design

Wholesale Stainless Steel Triple Strand Short Pitch Precision Roller Chain

Triple strand roller chain is also know as Triplex roller chain. Great quality roller chain at affordable prices.

Meets and exceeds ANSI B29.1 specifications
Roller chain components are shot peened for greater fatigue resistance
Heat treated components for increased durability, longevity and wear resistance
Chain is pre-loaded (Pre-stretched) to eliminate initial stretching.
Chain components are lubricated before assembly, then dipped in a hot oil bath after assembly

Chain N0.	Pitch	Roller diameter	Width between inner plates	Pin diameter		Pin length	Inner plate depth	Plate thickness	Breaking Load
	P	d1 max	b1 min	d2 max	L max	Lc max	h2 max	t/T max	Q
	mm	mm	mm	mm	mm	mm	mm	mm	kN
*25SS	6.350	3.30	3.18	2.31	7.9	8.4	6.00	0.8	2.5/568
*35SS	9.525	5.08	4.77	3.58	12.4	13.17	9.00	1.30	5.5/1250
40SS	12.700	7.95	7.85	3.96	16.6	17.8	12.00	1.50	9.6/2182
41SS	12.700	7.77	6.25	3.58	13.75	15.0	9.91	1.30	6.0/1360
50SS	15.875	10.16	9.40	5.08	20.7	22.2	15.09	2.03	15.2/3455
60SS	19.050	11.91	12.57	5.94	25.9	27.7	18.00	2.42	21.7/4932
80SS	25.400	15.88	15.75	7.92	32.7	35.0	24.00	3.25	38.9/8841
100SS	31.750	19.05	18.90	9.53	40.4	44.7	30.00	4.00	60.0/13636
120SS	38.100	22.23	25.22	11.10	50.3	54.3	35.70	4.80	72.5/16477
140SS	44.450	25.40	25.22	12.70	54.4	59.0	41.0	5.60	94.0/21363
04BSS	6.000	4.00	2.80	1.85	6.80	7.8	5.00	0.60	2.0/455
05BSS	8.000	5.00	3.00	2.31	8.20	8.9	7.10	0.80	3.5/795
#06BSS	9.525	6.35	5.72	3.28	13.15	14.1	8.20	1.30	6.2/1409
08BSS	12.700	8.51	7.75	4.45	16.7	18.2	11.80	1.0	12.0/2727
10BSS	15.875	10.16	9.65	5.08	19.5	20.9	14.70	1.70	14.5/3295
12BSS	19.050	12.07	11.68	5.72	22.5	24.2	16.00	1.85	18.5/4205
16BSS	25.400	15.88	17.02	8.28	36.1	37.4	21.00	4.15/3.1	40.0/9091
20BSS	31.750	19.05	19.56	10.19	41.3	45.0	26.40	4.5/3..5	59.0/13409
24BSS	38.100	25.40	25.40	14.63	53.4	57.8	33.20	6.0/4.8	104.0/25454
32BSS	50.800	29.21	30.99	17.81	66.0	71.0	42.00	7.0/6.0	150.0/34090

Stainless steel properties

Grade	Composition(%)						Temperature resisting	Specifications
Grade	C	Si	Mn	Ni	Cr	Mo	Temperature resisting	Specifications
1Cr13	≤0.15	≤0.6	≤0.6	-	12-14	-	650℃	Normal conveyor use
1Cr17	≤0.15	≤0.6	≤0.6	-	12-18	-	650℃	Normal conveyor use
304M	≤0.06	≤1.0	≤0.6	8.9-10	18-20	-	920℃	Normal conveyor use
304L	≤0.03	≤1.0	≤0.6	9-13	18-20	-	920℃	intercrystalline corrosion
316	≤0.08	≤1.0	≤0.6	10-14	16-18	2-3	920℃	Anti corrosion
316L	≤0.03	≤1.0	≤0.6	12-15	16-18	2-3	920℃	intercrystalline corrosion
309S	≤0.08	≤1.0	≤0.6	12-15	22-14	-	1000℃	Continuous high temperature
310s	≤0.08	≤1.5	≤0.6	19-22	24-26	-	1100℃	High temperature & heavy hit resisting
314	≤0.25	1.5-3.0	≤0.6	19-22	23-26	-	1200℃	Antioxidant plus all 310S
Cr20Ni80	≤0.15	0.4-1.3	≤0.6	72-78	20-23	-	1200℃	Antioxidant & high temperature resisting

Triple Strand Roller Conveyor Chain Stainless Steel Short Pitch Custom Design

Usual Tips

Item name:	Roller Conveyor Parts Roller Chain
Standard:	ANSI B29.1 M2002 (DIN 3183) and ISO 606.
Material:	40Mn, 45Mn,60Mn
Chain Type:	Single strand roller chain 16B with plastic attachment
MOQ:	Small order can be accepted
Delivery Time:	Sample: Within 2-3days Production:15-20 days
Port of delivery:	shenzhen/yantian
Payment Terms:	T/T,L/C, Paypal ,Western Union,
Shipment:	A. Send by Express – Swift delivery ( 4-7 working days) and we can get you a special price Shippment:UPS,TNT ,DHL,Chian post,EMS,FedEx ,etc.
	B. Send by Air: Arrive at destination Airport.
	C. Ship by Sea: Low shipping cost and slow delivery (15-30 days depends). Suitable for large quantity and non-urgent delivery.
Packing	Carton or wooden case, as your requirement
Supply Ability	200,000 pcs per month

Conveyor Chain FAQ

Q: What's the lead time?
A: It takes 5-10 days for production in factory depends the total quantity. Each belt is custom made based customer side exact parameters.

Q: How long is your company in business?
A: We shenzhen guangya wire belt company started business in 2003 and only dedicated to stainless steel chain & wire belt production.

Q: How do I order?
A: If you can visit our company, we can fix all technical details quickly by live discussion. We can also send you drawing so you can specify needed configuration. Once the wire belt structure is confirmed, we will sign contract. We accept T/T & L/C payment.

Q: How can I verify the belt?
A: Before delivery, you can send engineer to verify it by agreed technical design.
